Technical Data Technical Data Download |
Measuring Range | Display / Data Log | ||
Dewpoint F303Ax F303Bx F303Cx Temperature Pressure |
-60 … +60 °Ctd -80 … +20 °Ctd -110 … +20 °Ctd -40 … +100 °C 0 … 1.7 MPa(a) (Option) | Display Data Log | 7.0″ Touch LCD screen Max 16G USB Flash Disk |
Accuracy | Power | ||
Dewpoint (Air or Nitrogen) +60 … -60 °Ctd -60 … -100 °Ctd Temperature (Customized) 0 … + 50 °C -40 … 0 °C & +50 … +100 °C Pressure Accuracy Accuracy @23°C Pressure Drift With Temperature | ±2 °Ctd ±3 °Ctd ±0.3 °C (Standard) ±0.5 °C (Standard) ±0.3% FS ±0.001 MPa/10 °C | Power Battery capacity Charging batteries | 220 VAC 10 W 96 Wh 100 ~ 240 VAC, 50 ~ 60 Hz |
Response Time | Operating Environment | ||
Dewpoint: 63% [90%], Reference: 20 °C, 1bar(a), 4L/min | Operating temperature Storage temperature Relative humidity Sample gas flow rate Pressure | 0 … +50 °C -40 … +80 °C 0 … 95 %RH > 1 L/min 0 … 1.7 MPa(a) | |
-50 → +20 °Ctd +20 → -50 °Ctd Pressure | 20 sec [40 sec] 1 min [3 min] < 1 sec | ||
Other | |||
Process connection Sensor filter EMC | 6 mm Stainless steel quick connector Stainless steel sinter filter (Filtration class 30~45 um) Compliant with IEC 61326-1 | ||
Leaflet_F303x_Dewpoint Monitor_FIX_EN_2024-V3.02.pdf | 2.59MB | Download |
