F401x Standard Smart Pressure Transmitter

Pressure

Output

Measuring Range

Pressure Type

Accuracy

Hysteresis

Repeatability

Response

Measuring Medium

Overload Pressure

-100 ~ 0 kPa to 10 kPa ~ 40 MPa ~100 MPa

Gauge, Absolute, Negative pressure

0.5% (0.25% or 0.1% optional)

±0.1% FS

±0.1% FS

≤1 ms（Up to 90% FS）

Various liquids, gases or vapors

compatible with 316 stainless steel

2 times full scale

Analog Output

Digital Output

4 ~ 20 mA (2-wire)

Modbus RTU (RS485)

Power

Operating Environment

Power

16 ... 30 VDC

Medium Temperature

Environment Temperature

-30 ... +85 ℃

-40 ... +85 ℃

Others

Process Connection

Electrical connector

Protection Code

Housing Material

Diaphragm Material

G1/2"（M20x1.5, G1/4", 1/2"NPT,1/4"NPT optional）

Hirschmann DIN connectors

(Direct line out, airline connectors optional)

IP65

SUS304（SUS316 optional）

SUS316L
